CTM CT-10H - 10,000 BTU Marine Air Conditioner - 230V - 50/60HZ

Name: CTM CT-10H - 10,000 BTU Marine Air Conditioner - 230V - 50/60HZ
Brand: CTM Marine
Availability: InStock

CTM Marine

Availability:

In Stock - Ship within 1 - 2 Business Days

Rp40,192,988.25 - Rp43,398,564.00

(No reviews yet)

Condition:

New

Current Stock:

Quantity:

Adding to cart… The item has been added

50/60 Hz	Cooling or Heating
Dual Frequency	Reverse Cycle

Titanium (Ti) Coils	2-Year
Anti-Corrosive	Warranty

CTM CT-10H Marine Air Conditioner 10,000 BTU - 230V - 50/60HZ - Turbo Blower

CT-10 230V - 22201C

10,000 BTUs of powerful, quiet, and efficient cooling. 230V. Titanium circulating coils, stainless steel bolts, and stainless steel structural pan with ABS tray ensure long-lasting, corrosion-proof performance in even the toughest of marine environments. 2 Year Warranty*. Patent number.: US 12,030,610 B2.

The quiet, powerful, and efficient CTM is a great option for new installs but also works as the perfect drop-in replacement for all major marine A/C brands including Dometic, Webasto, Cruisair, Marine Air, and Mermaid Air. The CTM is fully compatible with all Dometic, Cruisair, Marine Air, and Micro Air controls/thermostats and cables, making replacement of those systems a breeze.

CTM has taken nearly a decade of experience as a top-selling marine A/C retailer in the US and combining this with an understanding of the wants and needs of marine A/C customers — as well as where other major brands could be improved — CTM has created a self-contained marine air conditioner and heat pump that raises the bar on quality and performance.

Substitute the following Part Numbers

CTM Unit Part Number	Description	Fits OEM Part number	OEM Description
22201C	CT-10 230V 50/60HZ 410A	205162109	DOMETIC DTG10 230V 50/60HZ 410A
		205162100	DOMETIC DTU10 230V 60HZ 410A
		205161100	DOMETIC DTU10 220V 50HZ 410A
		205161101	DOMETIC DTU10 220V 50HZ 410A 6MR
		205162101	DOMETIC DTU10 230V 60HZ 410A 6MR
		207500010	DOMETIC ECD10KZ/1-HV 410A KIT 220-240 50/60HZ
		205200150	DOMETIC GVTX10 115-230V 50/60HZ
		205563450	CRUISAIR STQ10C-410A 230V 60HZ
		205563455	CRUISAIR STX10C-410A 230V 60HZ
		205563400	MARINE AIR VTD10KZ-410A 230V 60HZ
		205563401	MARINE AIR VTD10KZ-410A 6"MR 230V/60HZ
		205563451	CRUISAIR STQ10C-410A 6"MR 230V 60HZ
		5011397A	WEBASTO FCF PLATINUM 10,000 BTUS 230V
		WBCL120002D	WEBASTO S10 BLUECOOL 10,000 BTUS 230V
		MSBA11C2	MARINAIRE 11,000 BTUS 230V 60HZ
		MSBA9C2	MARINAIRE 9,000 BTUS 230V 60HZ
		FM9H	FLAGSHIP 9,000 BTUS 230V COOL & HEAT
		FM9	FLAGSHIP 9,000 BTUS 230V COOL ONLY

And while lightweight and with a small footprint, the CTM CT includes titanium circulating coils, a high-velocity rotatable turbo blower (rotates less than 250 degrees), stainless steel bolts, and a stainless steel structural pan with Plastic ABS tray in order to ensure long-lasting, corrosion-proof performance in even the toughest of marine environments.

All CTM Control Boards, Temperature Sensors, and cables are made in the United States under strict quality standards. Every CTM Unit comes with an industry-standard 2-year warranty*, knowledgeable and attentive customer service, and ships ground to you free of charge within the US.

As marine A/C retailers, as well as boaters ourselves, we know what boaters are looking for in a marine A/C system — and this is exactly what the CTM line delivers

Specifications:

Capacity	10,000 BTU
Voltage	208-230 V
Cycle	50-60 Hz
Refrigerant Type	R410A
Input Cool / Heat	3.3 A / 3.9 A
Starting Amps	12 A
Locked Rotor Amps	22 A
Fuse Max. / Min.	15 A / 10 A
Blower Airflow	347 CFM
Blower Speed	1200 RPM
High-Velocity Blower	Yes
Min. Supply Duct Size	5 / 127 (in/mm)
Seawater Inlet Connection	5/8" / 16 (in/mm)
Suggested Water Flow	250 GPH
Net Weight	50 lbs / 23 kg

Features of the CTM CT-10

Compact Design

Perfect drop-in replacement for all major marine A/C Brands. Its compact design makes it the perfect unit for small spaces.

Electrical Box

Rugged electrical box with fire retardant cover.

Titanium Condenser Coil

The most corrosion-resistant material available for seawater cooling coils. 40% more resistant than copper, titanium coils guarantee top cooling performance and a rust-free environment.

Stainless Steel Frame Base

Corrosion-resistant stainless steel frame base will not rust or fall apart. Long-lasting and made to withstand the harsh marine environment.

ABS Insulated Pan

ABS is a versatile thermoplastic product that combines several compounds to offer a durable and corrosion-free material. This insulated pan is designed and made to last for years.

Quiet

Very quiet yet powerful marine air conditioning unit, making it a great option for powerboats and sailboats.

Turbo Blower

High-velocity rotatable turbo blower that will cool or hear faster. Blower rotates less than 250 degrees.

Universal Board

Next generation control board is compatible with most controllers in the market, such as OEM Brands like Dometic, Cruisair, and Marine Air. Also supports the TSEP Temperature sensor. Made in USA.

Reverse Cycle Heating

Enjoy powerful cooling from your CT Unit with the option of heating if needed. Thanks to reverse cycle, you can switch to heating when temperatures get low.

Digital Touch Control

The CT is compatible with the CTM Touch display - a 2.5" Color Display with the latest technology in the industry, including numerous programmable parameters, operational features, and much more.

Dimensions:

A - Width 20 in / 508 mm

B - Drain Pan Width 10 in / 254 mm

C - Height 13 in / 330 mm

D - Depth 12 in / 305 mm

E - Min. Duct Diameter 5 in / 127 mm

CTM CT Unit Cooling Efficient Design vs Competitors

Universal Control Board Layout

2-Year Warranty

CTM CT-10H - 10,000 BTU Marine Air Conditioner - 230V - 50/60HZ
